Real Time Data Acquisition and Logging Using NI RT-FPGA
Our portable data logging system supports following sensors and transducer types listed below for efficient capturing of sensor signals and post analysis.
- Flow
- Pressure
- Speed
- Thermo couple
- RTD
- Load Cell
- Voltage Measurement
- Current Measurement (CT)
- Torque
- Vibration
- Noise
Expandable
System has the flexibility to configure n-number of channels as per the needs. Provision to configure channel names, scaling and channel calibration for each channel or sensor is an added advantage.
Readable Logs
Data can be logged into the Database/Master PC in different file formats (CSV, XML, PDF) with absolute date and time. Users can configure the log rate or time interval from 1 millisecond (1 kHz). In addition, post-analysis modules and data review utilities can be provided with custom designs as per the user’s need.
Benefits
- Portable and modular logging system independent of PC and Internet
- Time deterministic real time system with FPGA for data acquisition
- Post analysis with custom tools
- Configurable based on the requirement
Features
- User defined channel scaling and calibration
- Expandable number of monitoring parameters/channels
- Expandable number of control parameters/channels as well
- High sampling rate data acquisition up to 1M samples per second
- Selectable channels and duration for logging
